Product Features

•Hot swappable OSFP Type2 external dimensions

• Equipped with a closed top radiator

• Supports 2x425Gb/s aggregated bit rate

• Power consumption<16W

• Compliant with RoHS regulations

• Laser eye level 1M

•The temperature range of the shell is from 0 ° C to+70 ° C (C temperature)

•Single 3.3V power supply

•Compliant with IEEE 802.3db

•8x100G PAM4 Rescheduled 106.25Gb/s

•PAM4 electrical interface complies with IEEE 802.3ck

•Dual MPO-12 APC socket

• I2C management interface

Application

• Unlimited Broadband Center

•800G SR8/VR8 application with FEC

•2x400G SR4/VR4 application with FEC

•8 x 100GbE branch applications

Product Features

•Hot swappable Type 2 OSFP external dimensions

• Supports 850Gb/s aggregated bit rate

• Power consumption<17W

• Meets RoHS-6 requirements

•The temperature range of the shell is 20 ° C to+60 ° C (extreme temperature) or 0 ° C to+70 ° C (c temperature)

•Single 3.3V power supply

• Compliant with IEEE 802.3bs requirements

•8x100G PAM4 re timed 106.25Gb/s PAM4 electrical, interface compliant with IEEE 802.3ck requirements

•Dual MPO-12, APC socket

• I2C management interface

Application

•8 x 100GbE applications

•2 x 400GbE applications

•4 x 200Gbe applications

•NDR Unlimited Broadband
